"STREET" HANDLEBARS
Variable diameter handlebars

7010 T6 aluminium aerospace quality
Oversize bar made with a variable diameter and wall thickness
1 1/8" (28,6 mm) diameter in the clamping area
7/8" (22,2 mm) diameter at the control ends
40% lighter and stronger than a classic bar
Laser etched to aid in handlebar centering and indexing
Knurled clutch side for the better grip hold

Warning, fluo colour designs are UV sensitive

Click on a colour to obtain the reference of the product
No-contractual photo. Color differences may appear depending on the screens.

black

#06014104
#06014113
#06014122

blue

#06014108
#06014117
#06014126

blue/orange

#06014112
#06014121
#06014130

green

#06014109
#06014118
#06014127

orange

#06014107
#06014116
#06014125

white/blue

#06014110
#06014119
#06014128

white/green

#06014111
#06014120
#06014129

yellow

#06014106
#06014115
#06014124

silver

#06014105
#06014114
#06014123

Tableau Universal mounting and Handlebar Clamps

Description Ref. NEKEN Ref. PARTS Color of design Width (mm) A Height (mm) A Sweep (mm) B Height (mm) B Sweep (mm)
NK OS STREET BAR LOW BK STR-LOW-BK 06014104 Handlebar Black - Low bend 752 130 75 100 60
NK OS STREET BAR LOW SL STR-LOW-SR 06014105 Handlebar Silver - Low bend 752 130 75 100 60
NK OS STREET BAR LOW FL YL STR-LOW-YEF 06014106 Handlebar with conical design Black - Low bend Fluo Yellow 752 130 75 100 60
NK OS STREET BAR LOW FL OR STR-LOW-ORF 06014107 Handlebar with conical design Black - Low bend Fluo Orange 752 130 75 100 60
NK OS STREET BAR LOW LIGHT BL STR-LOW-LBL 06014108 Handlebar with conical design Black - Low bend Light Blue 752 130 75 100 60
NK OS STREET BAR LOW FL GN STR-LOW-GRF 06014109 Handlebar with conical design Black - Low bend Fluo Green 752 130 75 100 60
NK OS STREET BAR LOW WH/BL STR-LOW-WH-BL 06014110 Handlebar with conical design Black - Low bend White-Blue 752 130 75 100 60
NK OS STREET BAR LOW WH/GN STR-LOW-WH-GR 06014111 Handlebar with conical design Black - Low bend White-Green 752 130 75 100 60
NK OS STREET BAR LOW OR/BL STR-LOW-OR-BL 06014112 Handlebar with conical design Black - Low bend Orange-Blue 752 130 75 100 60
NK OS STREET BAR MED BK STR-MED-BK 06014113 Handlebar Black - Medium bend 752 145 82 122 60
NK OS STREET BAR MED SL STR-MED-SR 06014114 Handlebar Silver - Medium bend 752 145 82 122 60
NK OS STREET BAR MED FL YL STR-MED-YEF 06014115 Handlebar with conical design Black - Medium bend Fluo Yellow 752 145 82 122 60
NK OS STREET BAR MED FL OR STR-MED-ORF 06014116 Handlebar with conical design Black - Medium bend Fluo Orange 752 145 82 122 60
NK OS STREET BAR MED LIGHT BL STR-MED-LBL 06014117 Handlebar with conical design Black - Medium bend Light Blue 752 145 82 122 60
NK OS STREET BAR MED FL GN STR-MED-GRF 06014118 Handlebar with conical design Black - Medium bend Fluo Green 752 145 82 122 60
NK OS STREET BAR MED WH/BL STR-MED-WH-BL 06014119 Handlebar with conical design Black - Medium bend White-Blue 752 145 82 122 60
NK OS STREET BAR MED WH/GN STR-MED-WH-GR 06014120 Handlebar with conical design Black - Medium bend White-Green 752 145 82 122 60
NK OS STREET BAR MED OR/BL STR-MED-OR-BL 06014121 Handlebar with conical design Black - Medium bend Orange-Blue 752 145 82 122 60
NK OS STREET BAR HIGH BK STR-HIGH-BK 06014122 Handlebar Black - High bend 752 170 80 144 60
NK OS STREET BAR HIGH SL STR-HIGH-SR 06014123 Handlebar Silver - High bend 752 170 80 144 60
NK OS STREET BAR HIGH FL YL STR-HIGH-YEF 06014124 Handlebar with conical design Black - High bend Fluo Yellow 752 170 80 144 60
NK OS STREET BAR HIGH FL OR STR-HIGH-ORF 06014125 Handlebar with conical design Black - High bend Fluo Orange 752 170 80 144 60
NK OS STREET BAR HIGH LIGHT BL STR-HIGH-LBL 06014126 Handlebar with conical design Black - High bend Light Blue 752 170 80 144 60
NK OS STREET BAR HIGH FL GN STR-HIGH-GRF 06014127 Handlebar with conical design Black - High bend Fluo Green 752 170 80 144 60
NK OS STREET BAR HIGH WH/BL STR-HIGH-WH-BL 06014128 Handlebar with conical design Black - High bend White-Blue 752 170 80 144 60
NK OS STREET BAR HIGH WH/GN STR-HIGH-WH-BL 06014129 Handlebar with conical design Black - High bend White-Green 752 170 80 144 60
NK OS STREET BAR HIGH OR/BL STR-HIGH-OR-BL 06014130 Handlebar with conical design Black - High bend Orange-Blue 752 170 80 144 60
